110V Paste Liquid
Heating
Stirring Filling
Machine |
|
The
semi-automatic piston filling machine produced by our company has the
advantages of simple and reasonable structure, high precision,
convenient cleaning and simple operation. The contact area with the
material is made of 304 stainless steel, in line with GMP requirements.
The sealing parts are made of PTFE and silica gel. They have the
advantages of corrosion resistance, aging resistance, high temperature
resistance, good sealing and so on. They are ideal filling equipment for
food, pharmaceutical, chemical, daily chemical, petroleum, pesticide and
other industries.
This machine
has two methods, foot switch filling and continuous automatic filling;
the two filling methods can be switched arbitrarily. It is recommended
to use the foot switch for filling at the beginning. |
 |
|
1.This product is designed for liquids , pasty fluid
, oil , and thin food products. It can help you to fill a mount of
quantitative liquids or pasty
fluid.
2.The
filling volume range is between 30ml - 300ml. And the machine should
connect air compressor for working.First time when you use the machine ,
you should weigh the weight of output by adjusting and make sure the
volume you want.
3.This series of models need to be
equipped with external air compressor, air compressor exhaust should not
be less than 0.1m3/min, equipped with pressure should be able to adjust
to 0.4-0.9Mpa range.
4.For the materials with large filling
viscosity and poor fluidity, which need heating or pressure , please consult us to recommend purchasing the mixing model,
heating model and heating mixing machine.
(Note1:We only sell machines, do not match air compressors, customers
need to buy their own.)
(Note2: If you are not sure whether the material can be filled with this
machine, please consult before placing an order) |
|
Product parameter: |
 |
|
Voltage: |
110V/60Hz |
|
Material |
The
surface is stainless steel |
| |
Pneumatic |
|
Filling volume (ml):
|
30-300ml |
|
Filling accuracy (FS) |
±0.5% |
|
Production capacity (cycle/min): |
1-25 |
|
Applicable tolerance (m3/min): |
≥0.1 |
|
Product size: |
30.3*11*38.97in(77*28*99cm) |
|
Net weight: |
（82.5lb） |
|
Applicable pressure (Mpa): |
0.4-0.9 |
|
|
Product analysis: |
 |
|
1.Pressure gauge assembly
2.Stainless steel body
3.Small cylinder
4.Water outlet
5.Emergency stop switch
6.Discharge assembly
7.Heating rod
8.Heating controller
9.Mixing motor
10.Heating and stirring double layer hopper
11.Water injection port (inlet for adding hot
oil or water)
12.Stainless steel hopper
13.Filling speed adjustment knob
14.cylinder
15.Magnetic switch
16.Quantitative hand wheel
|
|
This machine is suitable for materials with poor
fluidity, such as water, shampoo, toothpaste, honey, cream, lotion,
butter, ice cream and so on. |
|
Feature: |
 |
The barometer and the air inlet, the
air inlet is connected with the air compressor, easy to operate, stable. |
|
Magnetic switch, the use of hand wheel
rotation to adjust the filling amount, easy to operate. |
 |
 |
Adjust the rocker
filling precision
Hand handle, you can
adjust the amount of filling, easy to operate.
|
|
Emergency
stop switch
Emergency stop button
can stop machine action immediately.
|
 |
 |
Discharge assembly,
drip proof design
Filling nozzle, made of
stainless steel, accurate filling without plugging, removable easy to
clean and maintain.
|
|
This machine is equipped with a
high-quality mixing motor, which is more durable. |
 |
 |
This machine is equipped with a heating
controller, and customers can set the heating and insulation temperature
according to their needs. |
 |
|
(Refer to the right ring regulating valve and left
ring regulating valve in the figure above)
Adjust the speed of the cylinder moving piston rod:
The end near the moving rod (away from the handwheel) is the outlet
control valve (Adjust the speed of the cylinder moving rod to push out
the material);
The end away from the moving rod (near the handwheel) is the intake
control valve (Adjust the speed of cylinder moving rod recovery).
Clockwise downward, the discharge speed becomes slower;
Counterclockwise upward, the discharge speed becomes faster.
|
|
1..
This type of hopper is a heating and insulation hopper. If
customers use water as a medium for heating and insulation, there will
be a certain amount of heat loss through heating with a heating rod and
external environmental factors, and the maximum temperature can reach
around 90 degrees Celsius;
2.If customers want to reach a higher temperature, they can apply a
medium with a higher boiling point for heating and insulation (such as
heat transfer oil). Through heating with a heating rod and external
environmental factors, there will be a certain amount of heat loss, with
a maximum temperature of around 118 degrees Celsius;
3.Customers can also heat the material externally and pour it into the
hopper, which provides excellent insulation to ensure that the material
does not solidify during the filling process;
Note:
Our heating
temperature controller itself has no limit on the adjustable range, but
when applied to the hopper, the adjustable range is 0-118 degrees
Celsius (different media have different maximum temperatures)!
|
|
Product
safety precautions: |
|
This series of filling
machine is only suitable for filling liquid, low concentration paste .
To ensure safe production, please read the following precautions
carefully:
1. Use a power supply and air source that conforms to the requirements
of this machine . The stability of the air source must be maintained
under continuous working conditions.
2. Before disassembling, washing or repairing this machine, please be
sure to turn off the air source and power supply first.
3. The rear half of the machine (near the control buttons) and the lower
part of the machine frame are equipped with electrical control
components. Under no circumstances should the body be washed directly
with water, otherwise there will be danger of electric shock and damage
to the electrical control components.
4. After the power switch is turned off, there is still voltage in some
circuits in the electrical control of this machine. When repairing the
control circuit, please be sure to unplug the power cord.
5. Do not keep your eyes close to the filling head during work, pay
attention to personal safety.
6. Do not put your hand on the central axis of the cylinder during the
work process, pay attention to pinching your hands.
7. Before using materials for filling, it is best to clean the machine
with detergent first, and then clean it with clean water, so as to avoid
oil stains or foreign materials and materials mixing, which will lead to
waste of materials and damage to the machine.
|
|
Advantages： |
|
1. 304 stainless steel mixing bucket for more
convenient filling.
2. One touch operation, convenient and simple.
3. Rotating and stirring, material stirring
evenly, suitable for precipitation, sticky materials.
4. The use of diameter head, particulate
material will not be blocked.
5. Imported motor, lasting and durable, strong
power.
6. Imported pump, can be customized according to
the volume of filling models.
|
|
Details: |
 |
 |
 |
|
Product display: |
 |
 |
 |
 |
|
Affected by the
following factors at work:
1. The factors that affect the filling accuracy are: the stability of
the compressed air, the uniformity of the material, the filling speed,
etc.
2. The factors that affect the filling speed are: the viscosity of the
material, the stroke of the cylinder, the size of the cylinder, the size
of the discharge nozzle, the proficiency of the operator, etc.
|
|
Item Number: 160439 |
|
You can make order
with no worry.
Any concerns just feel free to let us know, we'll reply in 24 hours in
normal condition.
Handling Time: Shipping is usually made in 1-3 business days after
payments cleared. Orders are processed from Monday-Friday; Not on the
weekends & public holidays.
Warranty: 6 months' warranty for the machines, not for the consumables.
We stand behind our products all the item, so even if your warranty
period has expired, you can still seek for service or technical support
from us with low cost. |
|
